Single Stage Hammer Crusher

Publish Date:2026-01-25 17:43:41

China Pengfei Group Single Stage Hammer Crusher

Tel:+8615962749608





Description of Single- Stage Hammer Crusher:
Our PCF series single-stage hammer crusher is typically used in cement industry to crush mineral materials whose compressive strength is no more than 200MPa, such as limestone, gypsum, coal, malm, shale, and more.

It has features of big crushing ratio, simple structure, reliable performance, convenient maintenance, low operation costs, and that.








Technical Parameters of PCF Series Single- Stage Hammer Crusher:

ModelFeeding Size (mm)Discharge size (mm)Max. Feeding Size (mm)Rotor Diameter (mm)Rotor Length (mm)Production Capacity (t/h)Motor Power (kw)Weight (Excluding motor) (t)
PCF-14121290x1320≤25600x600x9001420120080-130130-19023.5
PCF-16161500x1785≤25800x800x100016501630130-240250-35043.3
PCF-18181750x1840≤25900x900x120018501730240-350400-56070
PCF-20182268x2130≤251000x1000x100020201820350-450630-71089
PCF-20222100x2380≤251000x1000x150020202230400-600630-800128


Note: Parameters in the form are only for reference, and specific ones should refer to the particular contract.
